Dyalog Quick Start Guide
Installation, Basics, and Your First Workflow
The following instructions should enable you to get started with a basic workflow in the Dyalog development environment.
Installing Dyalog
Installing Dyalog on Microsoft Windows
- Download the installer, extract the contents, and double-click on setup*.exe. We strongly recommend installing with administrator privileges.
- Starting Dyalog will launch the Dyalog for Microsoft Windows IDE.
Installing Dyalog on macOS
- Download the installer and double click the .pkg file.
- Starting Dyalog will launch Ride as the UI.
Installing Dyalog on Linux
- Download the interpreter installer
- Some desktop environments allow you to double click on the installer, otherwise:
- DEB-based:
sudo dpkg --install linux_64*.deb - RPM-based:
sudo rpm --install linux_64*.rpm
- DEB-based:
- Starting Dyalog will launch a TTY text-based interface
Optionally Install Dyalog Ride as the User Interface
- Download the Dyalog Ride installer
- DEB-based:
sudo dpkg --install ride*.deb - RPM-based:
sudo rpm --install ride*.rpm
- DEB-based:
- Starting Dyalog will launch Ride as the UI
Using Dyalog
The following information describes the basics of writing code and saving your work. For a more detailed walkthrough of installing Dyalog and beginning to use the development environments, see Chapter 2 of Mastering Dyalog APL.
Interactive Session (REPL)
2 + 3
5
Video: Overview of the Dyalog IDE for Microsoft Windows

Video: Overview of Dyalog Ride (Remote IDE for Dyalog)

Create, Trace, Edit, and Continue
Video: Editing and Debugging Dyalog APL

Video: Useful (Keyboard) Shortcuts in the Dyalog IDE

Save Your Work
]LINK.Create # /tmp/MyProject
Linked: # ←→ C:\tmp\MyProject [directory was created]
Whenever you make a change using the Editor (after closing it with Esc), a file will be created or updated in that directory. - variables and dfns defined using the assignment arrow in the session are not saved to a linked folder by default. Use
]LINK.Add mythingto save the source formythingwith your code. - tacit functions cannot be saved as text source, they must be wrapped in a tradfn or dfn.
Video: Introduction to APL Namespaces

Quit Dyalog
Use ⎕OFF, or close the window, to exit Dyalog.
Resume Your Work
When you next start Dyalog, you can scroll up in the session log to see your previous input and output.
Use ]LINK.Create # /tmp/MyProject again (you can click on the line from before and press Enter) to resume working on the code you saved earlier.
If you’re struggling to install and/or start using Dyalog, email us at support@dyalog.com, call +44 1256 830030, or send us a message.
Rich Park, APL Teacher/Evangelist
